IBP

Mulcher designed for tractors between 30 HP to 80 HP for the maintenance of vegetable mantle and for the elimination of remains of pruning up to 5 cm.

IBP

Mulcher designed for tractors between 30 HP to 80 HP for the maintenance of vegetable mantle and for the elimination of remains of pruning up to 5 cm.

Characteristics:

  • Steel-plate chassis, thickness 6 mm.

  • Tubular rotor of Ø 400 mm.

  • Gearbox with freewheel included.

  • Synchronous belts transmission.

  • Forged hammers SERRAT special “grass”

  • 2 lines of counter knives screwed in.
  • GIROSTOP System.

  • Supports of bearing rotor in steel.

  • Oscillating bearings of double row
    of rollers.

  • Supports of bearing rotor in steel.
  • Rear hood with double position.
  • PTO 540 rpm.

  • Double bearing on rear roller.

  • Height-adjustable rear roller.

  • Turret with 4 hooking positions.

  • Width cover belts 84 mm.

  • Model built under EC Normative.

  • Safety indicators visible to personnel.



Advantage Serrat:

Advantage Serrat:

IBP in action

Z

HYDRAULIC DISPLACEMENT

Discover IBP
