Dap FX

Offset mulcher of high range with forestry rotor, for works in agricultural margins, banks, highways, channels, roads and others clears of public works for tractors between 120-180 CV. It incorporates safety system thanks to a valve positionned in the cylinder of elevation of the arm.

Angulation +90º / -65º.

Rotor POLSER+ of 550 mm Ø with forestry SERRAT hammer swinging 360º.

Dap FX

Offset mulcher of high range with forestry rotor, for works in agricultural margins, banks, highways, channels, roads and others clears of public works for tractors between 120-180 CV. It incorporates safety system thanks to a valve positionned in the cylinder of elevation of the arm.

Angulation +90º / -65º.

Rotor POLSER+ of 550 mm Ø with forestry SERRAT hammer swinging 360º.

Characteristics

  • Non-wear steel-plate chassis, thickness 10 mm.

  • Rotor POLSER+ of Ø 550 mm.

  • Gearbox SERRAT.

  • 4 XPC side belt transmission.

  • Double transmission with a centre shaft and homocinetic knot on the second transmission.

  • Supports of bearing rotor in steel.

  • Height-adjustable rear roller.

  • PTO 1.000 rpm.

  • Oscillating bearings of double row of rollers.
  • Front protection curtain.

  • Front skid shoes.

  • Double bearing on rear roller.

  • Angulation +90º/-65º.

  • Hydraulic lateral offset mulcher.

  • Safety valve.

  • Model built under EC Normative.

  • Safety indicators visible to personnel.

Advantages Serrat:

Advantages Serrat:

Dap FX in action
