Dap +

Offset mulcher of high range with agricultural rotor, for works in agricultural margins, Banks, highways, channels, roads and others clears of public works for tractors between 120-160 HP.

It incorporates safety system with springs.

Angulation +90º / -65º Rotor POLSER of 550 º

Dap +

Offset mulcher of high range with agricultural rotor, for works in agricultural margins, Banks, highways, channels, roads and others clears of public works for tractors between 120-160 HP.

It incorporates safety system with springs.

Angulation +90º / -65º Rotor POLSER of 550 º

Characteristics

  • Non-wear steel-plate chassis, thickness 10 mm.

  • Rotor POLSER of Ø 550 mm.

  • Gearbox SERRAT.

  • 4 XPC side belt transmission.

  • Double transmission with a centre shaft and homocinetic knot on the second transmission.

  • Supports of bearing rotor in steel.

  • Height-adjustable rear roller.

  • PTO 1.000 rpm.
  • Oscillating bearings of double row of rollers.
  • Front protection curtain.

  • Front skid shoes.

  • Double bearing on rear roller.

  • Angulation +90º / -50º.

  • Hydraulic lateral offset mulcher.

  • Safety valve.

  • Model built under EC Normative.

  • Safety indicators visible to personnel.

Advantages Serrat:

Advantages Serrat:

DAP+ in action
