Evolution Fixed con Portón

Mulcher of hammers, for the elimination of remains of pruning up to 8 cm and maintenance of vegetable mantle. Ideal for the regeneration of meadows and grassland.
Rotor POLSER of 480 mm of diameter.
Excellent results in industrial gardening and maintenance of borders.
Its fixed configuration allows to choose the position of the gearbox to reach the work camp and that the transmission works straight line.

Evolution Fixed con Portón

Mulcher of hammers, for the elimination of remains of pruning up to 8 cm and maintenance of vegetable mantle. Ideal for the regeneration of meadows and grassland.
Rotor POLSER of 480 mm of diameter.
Excellent results in industrial gardening and maintenance of borders.
Its fixed configuration allows to choose the position of the gearbox to reach the work camp and that the transmission works straight line.

  • Steel-plate chassis, thickness 10 mm.

  • Rotor POLSER of Ø 450 mm.

  • Gearbox SERRAT.

  • 3 XPC side belt transmission.

  • Forged agricultural hammers Serrat
    Hammers guaranteed against breakage.

  • GIROSTOP System.

  • Supports of bearing rotor in steel.

  • Oscillating bearings of double row of rollers.

  • Front protection curtain.

  • Obturations antiwire in rotor.
  • Double bearing on rear roller.
  • Rear height-adjustable roller Ø 180/210 mm.
  • PTO 540 rpm.
  • Rear tine retaines (optional).
  • Rear roller cleaner.
  • Steel counter hammers.
  • Rear hydraulic hood with sieve.
  • Front skid shoes.
  • Model built under EC Normative.
  • Safety indicators visible to personnel.

Advantages Serrat:

Advantages Serrat:

Evolution Fixed con Portón en acción

Z

free wheel in sleeve

Z

free wheel in transmission

Discover Evolution Fixed con Portón
