Pro Con Portón

Polyvalent mulcher for the elimination of remains of pruning, in citrus fruits, fruit trees, olive trees and clear of matter in foot. Rear hydraulic gate with sieve, replaceable breakers and roller of control for the soil.

It allows to be employed at both directions, attacking big volumes, at the same hooking position.

It protects the tractor of pricks and breakdowns not having to tread on the material to mulch.

Pro Con Portón

Polyvalent mulcher for the elimination of remains of pruning, in citrus fruits, fruit trees, olive trees and clear of matter in foot. Rear hydraulic gate with sieve, replaceable breakers and roller of control for the soil.

It allows to be employed at both directions, attacking big volumes, at the same hooking position.

It protects the tractor of pricks and breakdowns not having to tread on the material to mulch.

Characteristics:

  • Steel-plate chassis, thickness 10 mm.

  • Rotor POLSER of Ø 550 mm.

  • Gearbox SERRAT.

  • 3/4 XPC side belt transmission.

  • Forged agricultural hammers Serrat.

  • Hammers guaranteed against breakage.
    GIROSTOP System.

  • Supports of bearing rotor in steel.

  • Oscillating bearings of double row of rollers.

  • Front protection curtain.

  • Obturations antiwire in rotor.
  • Double bearing on rear roller.
  • Rear height-adjustable roller.
  • PTO 540 rpm.
  • Rear hydraulic hood with sieve.
  • Rear roller cleaner.
  • 11 lines of counter hammers.
  • Front skid shoes.
  • Model built under EC Normative.
  • Safety indicators visible to personnel.

Advantages Serrat:

Advantages Serrat:

Pro Con Portón in action

Z

Hydraulic rear door with screen

Z

rollers 11 mm radio 210

Z

front skates

Z

freewheel in sleeve

Z

freewheel in transmission

Discover Pro Con Portón
