Forestry heavy duty brush culter with unit-body construction of 15 mm of thickness.
Gearbox up to 150 HP.
Suitable for work of clearing brush, creation of grassland, fallow fields and electrical lines, with bushes in foot up to 8 cm. Frame with unit-body construction. Top reinforcements and plates antispoil low, to avoid the shock of the chains against the chassis.
Plate with system of anchorage of chains with linkage parts.
Steel-plate closed or open chassis, thickness 15 mm + 10 mm.
PTO 1.000 rpm.
SERRAT rotor with 4 chains with links
of Ø 16 mm.
Front protection curtain.
Lower reinforcements (links of chains).
Transmission with freewheel.
Model built under EC Normative.
Safety indicators visible to personnel.
FX CADENAS in action
open or closed
