Splinter 450

Mulcher with reversible hydraulic feeder, ideal for pruning of olive trees, citrus trees and nuts.
Adapted to crush residues from 8-10 cm of diameter, with the rotor SPLINTER of SERRAT which is adapted for tractors between 70 and 140 HP.
It works in reverse to preserve the tractor for doesn’t pass at the top of the branches.

Splinter 450

Mulcher with reversible hydraulic feeder, ideal for pruning of olive trees, citrus trees and nuts.
Adapted to crush residues from 8-10 cm of diameter, with the rotor SPLINTER of SERRAT which is adapted for tractors between 70 and 140 HP.
It works in reverse to preserve the tractor for doesn’t pass at the top of the branches.

Characteritics

  • Steel-plate chassis, thickness 8 mm.
  • Rotor with SPLINTER technology of Ø 450 mm.
  • Gearbox SERRAT for tractors between 70 and 140 HP.
  • 3 XPC side belt transmission.
  • Treated blades.
  • Feeder with system BRALAKC.
  • High torque hydraulic motor reversible.
  • Supports of bearing rotor in steel.
  • High speed and high strength bearings.
  • PTO 540 (110 HP) or 1.000 rpm (140 HP).
  • Double bearing on rear roller.
  • Triple feed chain.
  • 2 lines of counter knives screwed in.
  • Model built under EC Normative.
  • Safety indicators visible to personnel.

Advantages Serrat:

Advantages Serrat:

SPLINTER 450 in action

Z

2 lines of counter knives screwed in

Z

Rotor SPLINTER Technology

Discover Splinter 450
